Product Name:
6 AWG SAE J1127 low voltage battery cable
Number :
 |
We offer battery cables SGT and STX/SGX. All auto battery cable options meet SAE J-1127, Ford and Chrysler
specifications.
Battery wire also comes in a variety of AWG sizes.
Our battery cable features bare copper conductors and is available in standard battery circuit black and red.
SGT cable can be used in starter or battery ground circuits.
It comes with Polyvinylchloride (PVC) insulation and can withstand temperatures up to 105ºC.
Flex SGT wire is available with higher stranding.
STX wire or SGX wire can be used for automotive starters or battery grounds where resistance to abrasion,
heat and aging is needed.
It has Cross-Linked Polyethylene (XLPE) insulation and can withstand temperatures up to 125ºC.
SGT Automotive Battery Cable/Automotive Starter, Ground or Battery Cable
Construction:
Conductor: Bare copper
Insulation: Polyvinylchloride (PVC)
Color & Print Options: Available in standard battery circuit colors of black and red with optional custom printing available.
Stranding Options: SGT Cable is available with higher stranding.
Applications:
Type SGT Battery Cable may be used in starter or battery ground circuits in accordance with SAE J-1127.
Recommended temperature range is -40°C to +105°C.
Manufactured to meet Ford (M1L-56A) and Chrysler (MS-3450)
|
SGT Automotive Battery Cable |
|
|||||
|
AWG Size |
Conductor Stranding |
Nom. Insul. Thick. (in) |
Nom. O.D. (in) |
Approx LBS/MFT |
SAE Spec |
|
|
6 |
37/.0260 |
0.06 |
0.305 |
137 |
SAE J-1127 |
|
|
4 |
61/.0250 |
0.065 |
0.35 |
168 |
SAE J-1127 |
|
|
2 |
133/.0218 |
0.065 |
0.44 |
258 |
SAE J-1127 |
|
|
1 |
133/.0243 |
0.065 |
0.48 |
322 |
SAE J-1127 |
|
|
1/0 |
133/.0275 |
0.065 |
0.525 |
431 |
SAE J-1127 |
|
|
2/0 |
133/.0309 |
0.065 |
0.575 |
497 |
SAE J-1127 |
|
|
3/0 |
361/.0210 |
0.078 |
0.661 |
603 |
SAE J-1127 |
|
|
4/0 |
361/.0239 |
0.078 |
0.726 |
779 |
SAE J-1127 |
|
Noted:
Primary auto wire is designed for many different automotive environments and to endure the harsh conditions
of a variety of automotive applications. Allied's automotive wiring ranges from commercial to recreational vehicles.
