-Compatible

-Double seal rings for better waterproof effect

-Compatible with PV cables with different insulation diameters

-It can be used in harsh environment

-With excellent aging resistance and UV endurance

-Created seal, design of dust proof

-Load capability with big current and high voltage

-Quick & simple assembly processing and simple removal of plugs without the aid of any extra instrument

-Strong pulling force capability

-Resistance of extra high & low temperature and fireproof

-Lower contact resistance

Specification:

Insulation material:TPE PPO

Rated current;15A

Rated voltage:1000V(TUV)&600V(UL)

Test voltage:6kV(50Hz,lmin)

Typical contact resistance:≤0.2mmΩ

Contact material:Copper,Tin plated

Degree of protection:IP67

Safety degree:ll

Material RTl:110℃

Ambient temperature range:-40℃ until+85℃
