Product Name:
GPT Automotive Primary Wire
Number :
 |
Conductor: Bare Copper
Insulation: Polyvinylchloride (PVC)
Options: is available in solid colors and stripes with optional custom printing and/or numbering
Ratings and Approvals:
Temperature Range: -40°C to +80°C
Meets Ford (M1L-56A) and Chrysler (MS-3450) specifications
Applications:
be used whenever SAE J-1128 specifies general circuit wiring
|
AWG Size |
Conductor Stranding |
Nom. Insul. Thick. (in) |
Nom. O.D. (in) |
Approx LBS/MFT |
SAE Spec |
|
22 |
7/30 |
0.023 |
0.076 |
3.9 |
SAE J-1128 |
|
20 |
7/28 |
0.023 |
0.084 |
6.2 |
SAE J-1128 |
|
18 |
16/30 |
0.023 |
0.093 |
8.3 |
SAE J-1128 |
|
16 |
19/29 |
0.023 |
0.102 |
11.5 |
SAE J-1128 |
|
14 |
19/27 |
0.023 |
0.118 |
16.8 |
SAE J-1128 |
|
12 |
19/25 |
0.026 |
0.141 |
25.2 |
SAE J-1128 |
|
10 |
19/23 |
0.031 |
0.178 |
40 |
SAE J-1128 |
|
8 |
19/21 |
0.037 |
0.218 |
63 |
SAE J-1128 |
Noted:
Primary auto wire is designed for many different automotive environments and to endure the harsh conditions
of a variety of automotive applications. Allied's automotive wiring ranges from commercial to recreational vehicles.
Our Primary Wire is top of the line and has excellent features.
All of primary automotive wire1 meets SAE J-1128, Ford and Chrysler specifications. Products in our inventory include,
SXL, GXL, TXL, GPT, TWP and HDT.
While some primary wire is rated for general use, such as circuit wiring, others are used in more specific scenarios,
such as GXL which is mostly used in trucks and trailers.
SXL wire is used in applications that have a need for high heat resistance and high temperature performance.
It is therefore rated up to 125°C whereas GPT and HDT are rated to only 80°C.
We also boast a range of sizes for certain types of automotive primary wire that include 22 AWG to 4/0 AWG.
