Product Name:
GXL Automotive Primary Wire/Automotive Primary Wire
Number :
 |
Construction:
Conductor: Bare Copper
Insulation: Thin wall Cross-linked Polyethylene (XLPE)
Colors & Print Options: Available in solid colors or with stripes, as well as optional custom printing and/or numbering.
Features:
GXL Wire is intended for use in engine compartments where higher heat resistance is required according to SAE J-1128.
Recommended temperature range: -51°C to +125°C.
Available in drumpacks on many sizes
Also meets Ford (M1L-85B) and Chrysler (MS-8900)
|
GXL Automotive Primary Wire/Automotive Primary Wire |
|||||
|
AWG Size |
Conductor Stranding |
Nom. Insul. Thick. (in) |
Nom. O.D. (in) |
Approx LBS/MFT |
SAE Spec |
|
20 |
7/28 |
0.023 |
0.084 |
6 |
SAE J-1128 |
|
18 |
16/30 |
0.023 |
0.094 |
8 |
SAE J-1128 |
|
16 |
19/29 |
0.023 |
0.104 |
11.5 |
SAE J-1128 |
|
14 |
19/27 |
0.023 |
0.116 |
16 |
SAE J-1128 |
|
12 |
19/25 |
0.026 |
0.141 |
24 |
SAE J-1128 |
|
10 |
19/23 |
0.031 |
0.174 |
37 |
SAE J-1128 |
|
8 |
19/21 |
0.037 |
0.218 |
68 |
SAE J-1128 |
Noted:
Primary auto wire is designed for many different automotive environments and to endure the harsh conditions of a variety
of automotive applications. Allied's automotive wiring ranges from commercial to recreational vehicles.
Our Primary Wire is top of the line and has excellent features.
All of primary automotive wire1 meets SAE J-1128, Ford and Chrysler specifications. Products in our inventory include, SXL,
GXL, TXL, GPT, TWP and HDT.
While some primary wire is rated for general use, such as circuit wiring, others are used in more specific scenarios,
such as GXL which is mostly used in trucks and trailers.
SXL wire is used in applications that have a need for high heat resistance and high temperature performance.
It is therefore rated up to 125°C whereas GPT and HDT are rated to only 80°C.
We also boast a range of sizes for certain types of automotive primary wire that include 22 AWG to 4/0 AWG.
