Product Name:
Rvs solid wire single core cable Copper Core
Number :
 |
1, Standard: GB/T9330/IEC60332 or according to customer's requirements
2, Voltage: 450/750V
3, Application: Multicore Control cable applies to controlling, monitoring and protective system with A. C.
Rated voltage 450-750V and below.
4, Nominal cross section size of conductor: 0.75 mm2, 1 mm2, 1.5mm2, 2.5mm2, 4mm2, 6mm2, 10mm2
5, multicore, Cores available: 4 cores, 5 cores, 6 cores, 7 cores, 8 cores, 10 cores, 14 cores, 16 cores, 19 cores,
24 cores, 30 cores, 37 cores.
Rvs Electric 1mm solid wire single core cable Copper Core
|
Nominal cross section of conductor |
Min number of single line in the stranded conductor |
insulator thickness |
sheath thickness |
Upper value of average overall diameter |
Min insulation resistance under temperature 700C MΩ.km |
| mm2 | mm | mm | mm | ||
| 3×0.75 | 1 | 0.6 | 0.9 | 4.6×9.6 | 0.012 |
| 3×1.0 | 1 | 0.6 | 0.9 | 4.8×10.1 | 0.011 |
| 3×1.5 | 1 | 0.7 | 0.9 | 5.3×11.7 | 0.011 |
| 3×2.5 | 1 | 0.8 | 1 | 6.2×14.0 | 0.01 |
| 3×4 | 1 | 0.8 | 1 | 7.0×15.8 | 0.0085 |
| 3×4 | 7 | 0.8 | 1 | 7.0×15.8 | 0.008 |
| 3×6 | 1 | 0.8 | 1.1 | 7.8×18.2 | 0.007 |
| 3×6 | 7 | 0.8 | 1.1 | 7.8×18.2 | 0.0065 |
| 3×10 | 7 | 1 | 1.2 | 9.5×23.0 | 0.0065 |
Note:
1.Insulator:PVC/C type PVC mixture is adopted as insulating material
2.Sheath:PVC/ST4 model PVC mixture should be adopted as the inner sheath.
3.The overall dimension should be within the limitation stipulation of the table
