UL1332 300V 200c 24AWG 22AWG 20AWG 18AWG FEP Insulated Electrical Wire

Product Name:

UL1332 300V 200c 24AWG 22AWG 20AWG 18AWG FEP Insulated Electrical Wire

Number :

Product Description:

Product features:

Good corrosion-resistance,almost doesn't melt any organic imp regnant,Oil-resistance,strong acid-resistance, strong alkali-resistance,
oxidant-resistance and so on.Bear the good electric insulated capability, high voltage-resist,moisture-resistance,high insulation resistance;
Flame-retardant, Anti-ageing, long age of usage

Rated voltage:600V and below
Test of power-frequency withstand voltage:3000V
Temperature range:-65~+250ºC
Conductor: Tinned copper or Silver-plated copper
Insulation: FEP, PFA , PTFE according to customer's request
Color:Red yellow blue green white black orange purple brown

UL1332 300V 200c 24AWG 22AWG 20AWG 18AWG FEP Insulated Electrical Wire

Conductor			Insulation		Over Diameter
AWG	No./mm	Out.Dia. mm	Avr.Thick. mm	Min.Thick. mm	average mm	tolerance mm
20	19/0.19	0.95	0.15	0.10	1.25	±0.10
22	19/0.15	0.75	0.15	0.10	1.05	±0.10
24	7/0.20	0.61	0.15	0.10	0.91	±0.10
26	7/0.16	0.48	0.15	0.10	0.78	±0.10
28	7/0.127	0.38	0.15	0.10	0.68	±0.10
30	7/0.10	0.30	0.15	0.10	0.60	±0.10
32	7/0.08	0.24	0.15	0.10	0.54	±0.10
