Silicon Rubber (flame retardant) Flat Power Cable

Product Name:

Silicon Rubber (flame retardant) Flat Power Cable

Number :

Product Description:

Silicon Rubber (flame retardant) Flat Power Cable

Performance for Usage

1) Rated voltage UO/U:0.6/1kV
2) Working temperature allowed:
-60ºC~+180ºC for cable with silicon rubber insulation;
-60ºC~+200ºC for cable with fluoroplastics insulation
3) Max temperature of cable conductor is no more than 250ºC during short circuit(the longest lasting time is no more than 5s).
4)Temperature for installing is no lower than -20ºC. 5: Min. bending radius of cable is 10 times that of
small border length of cable.

Type and Description

Type	Description
(ZR)-YGCB	(flame retardant)Flat power cable with silicon rubber insulation and sheath
(ZR)-YF46GRB	(flame retardant)Flat power cable with F insulation and silicon rubber sheath

Main Performance Parameter

Cross section area	0.75	1	1.5	2.5	4	6	10	16	25	35	50	70	95	120	150	185
Romax (Ω/km)	26.0	19.5	13.3	7.98	4.95	3.30	1.91	1.21	0.780	0.551	0.386	0.272	0.206	0.161	0.129	0.106

Nominal cross section area	Conductor diameter	Insulation thickness	Sheath thickness	Space	Cable O D	Weight(kg)
4×1	1. 2 9	0 . 8	1. 6	1	17. 76×6.0 9	2 25
6×1	1. 2 9	0 . 8	1. 6	1	25 . 5 4×6.0 9	3.8
8×1	1. 2 9	0 . 8	1. 6	1	3 3 . 32×3.0 9	3 6 0
4×1. 5	1. 5 6	1	1. 6	1	2 0 . 4 4×6. 76	291
6×1.5	1.5 6	1	1. 6	1	29 .5 6×6. 76	3 6 0
8×1. 5	1. 5 6	1	1. 6	1	3 8 . 6 8×6. 76	4 6 9
4×2.5	2. 0 5	1. 4	1. 6	1.5	27.1×8 . 0 5	333
6×2.5	2. 0 5	1. 4	1. 6	1.5	39 .8×8. 0 5	5 3 6
8×2.5	2. 0 5	1. 4	1. 6	1.5	52.5×8. 0 5	6 0 8
4×4	2 . 6 0	1. 8	1. 7	1. 7	3 3 . 3×9. 6	4 57
6×4	2 . 6 0	1. 8	1. 7	1. 7	4 9 .1×9. 6	79 0
4×6	3 .15	2	1. 9	2 . 0	3 8 . 4×11. 5	615
6×6	3 .15	2	1. 9	2 . 0	5 6 . 7×11. 5	10 9 8
