Flat Silicone Ribbon Flexible Cable
 |
Product Name:
Flat Silicone Ribbon Flexible Cable
Number :
 |
Product Description:
Flat Silicone Ribbon Flexible Cable
A silicone ribbon cable is a cable with many conducting wires running parallel to each other on the same flat plane.
As a result the cable is wide and flat. Its name comes from its resemblance to a piece of ribbon.
As a result the cable is wide and flat. Its name comes from its resemblance to a piece of ribbon.
The silicone rubber flat cable is suitable for the connecting cable of drinking water, industrial water and underwater electrical.
The silicone rubber sheath cable is suitable for track system, especially for the working environment of repeated mobile and strong
bending working environment with hoist, elevator and drum machine.
The silicone rubber sheath cable is suitable for track system, especially for the working environment of repeated mobile and strong
bending working environment with hoist, elevator and drum machine.
|
Type
|
Description
|
No. Of cores
|
Nominal
cross-section (mm²) |
Rated voltage(V)
|
|
YFFB
|
NBR Insulated and Sheathed, Flat Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YFFBP
|
NBR Insulated and Sheathed, Shield Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YFFBJ
|
NBR Insulated and Sheathed, Adding Steel Wire Flat Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YVFB
|
NBR Insulated PVC Sheathed, Flat Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YVB
|
PVC Insulated and Sheathed, Flat Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YGGB
|
Silicone Rubber Insulated and Sheathed, Tinned Copper, Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
TR
|
Electric hoist Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YZBP
|
Middle Voltage Copper Brained Shield Ribbon Flexible Rubber Cable
|
2~28
|
0.75~150
|
300/500V
|
|
YCBP
|
High Voltage Copper Brained Shield Ribbon Flexible Rubber Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YVFBP
|
NBR Insulated PVC Sheathed, Shield Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YFFBP
|
NBR Insulated and Sheathed, Shield Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YVBP
|
PVC Insulated and Sheathed,Copper Braided Shield Ribbon Flexible Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YZWBP
|
Oil Resistant Middle Voltage Copper Braided Shield Flat Ribbon Flexible Rubber Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YCWBP
|
Oil Resistant 450/750v Copper Braided Shield Ribbon Flexible Rubber Cable
|
2~28
|
0.75~150
|
450/750V
|
|
YGCB
|
Silicone Insulated and Sheated, High Voltage Ribbon Flexible Cable
|
3
|
10~150
|
6/10KV
|
|
YGCBP
|
Silicone Insulated and Sheated, High Voltage Ribbon Shield Flexible Cable
|
3
|
10~150
|
6/10KV
|
|
YGVFB
|
NBR Insulated PVC Sheathed, High Voltage Ribbon Flexible Cable
|
3
|
10~150
|
6/10KV
|
|
YGVFPB
|
NBR Insulated PVC Sheathed, High Voltage Shield Ribbon Flexible Cable
|
3
|
10~150
|
6/10KV
|
