3KW 5KW 7KW 11KW 15KW solar water submersible pump cable

Product Name:

3KW 5KW 7KW 11KW 15KW solar water submersible pump cable

Number :

Product Description:

FEATURES & PROPERTIES :

Meets the requirement of CENELEC HD 22.1.S2, DIN VDE 0282 PART 810, IEC 245, CEI 20-19 & BS 6007, BS 6899.
Designed for heavy duty use.
Cur, tear & abrasion resistant.
Exceptional long term performance.
Excellent resistant to oils, chemicals,ozone & solvents.
Excellent Impact Resistant.
Excellent Weather Resistant.
Performs & Looks like Vulcanize Rubber.
Excellent Electrical Properties.

APPLICATION :
For continuous use in deep well to supply power to submersible pumps down to depths of 500 mtrs.

CONSTRUCTION :
Conductor : Finely stranded bare copper flexible conductor.
Insulation : Oil & water resistant thermoplastic rubber,
Sheath : Black heavy duty thermoplastic rubber.
Core Colours :
3core: Red ,Yellow and Blue.
3core: Black,Light Blue and Brown

Flat Jacketed Submersible Pump Cables Without Ground
CONDUCTOR SIZE (AWG)	NO OF CONDUCTOR	Nos & Dia. of Wire	Ground Conductor Size (AWG)	CORE DIA. (MM)	NOMINAL SHETH THICKNESS (MM)	CABLE DIA. (MM)
14	3	41 X 0.254	14	3.85	1.15	18.00 x6.50
12	3	65 X 0.254	12	4.5	1.15	21.00 x7.60
10	3	105 X 0.254	10	5.3	1.15	24.30 x7.90
8	3	168 X 0.254	10	6.5	1.4	29.70 x9.90
6	3	266 X 0.254	8	8	2	36.00 x11.80
4	3	420 X 0.254	8	10.1	2	45.10 x14.70
2	3	665 X 0.254	6	11.3	2.2	50.10 x16.20
1	3	817 X 0.254	6	13.6	2.2	58.10 x19.00
1/0	3	1045 X 0.254	6	15.6	2.2	58.10 x19.00
2/0	3	1330 X 0.254	6	18	2.2	66.50 x21.50
