Tinned Copper/Copper electric motor winding wire

Product Name:

Tinned Copper/Copper electric motor winding wire

Number :

Product Description:

FEATURES & PROPERTIES :
Meets the requirement: VDE 0282 PART 810, IEC 245, CEI 20-19 & BS 6007, BS 6899.
Designed for heavy duty use.
Cur, tear & abrasion resistant.
Exceptional long term performance.
Excellent resistant to oils, chemicals,ozone & solvents.
Excellent Impact Resistant.
Excellent Weather Resistant.
Performs & Looks like Vulcanize Rubber.
Excellent Electrical Properties.

APPLICATION :
For continuous use in deep well to supply power to submersible pumps down to depths of 500 mtrs.

CONSTRUCTION :
Conductor : Finely stranded bare copper flexible conductor.
Insulation : Oil & water resistant thermoplastic rubber,
Sheath : Black heavy duty thermoplastic rubber.
Core Colours :
4core: Red , Yellow Blue, Green Or Black

core: Black, Light Blue, Brown, Yellow with green line Or Green with yellow line

4CORE ROUND CABLES FOR SUBMERSIBLE PUMPS (1100 VOLTS)
Conductor		Insulation		Sheath		Conductor Resistance at 20℃ (max)
Nominal Area	No. & Dia. of wire	Nominal Thickness	Nominal Core Dia.	Nominal Thickness	Approx. Overall Dia
Nominal Area	No. & Dia. of wire	Nominal Thickness	Nominal Core Dia.	Nominal Thickness	Approx. Overall Dia
1.5	22/0.30	0.8	3.25	1.5	10.8	12.1
2.5	36/0.30	0.9	3.84	1.65	12.5	7.41
4	56/0.30	1	4.5	1.65	14.1	4.95
6	85/0.30	1	5.3	1.65	16	3.3
10	140/0.30	1	6.5	2	20.35	1.91
16	226/0.30	1	8	2	23.4	1.21
25	354/0.30	1.2	10.1	2.2	28.8	0.78
35	495/0.30	1.2	11.5	2.2	31.5	0.554
50	703/0.30	1.4	13.6	2.3	37.3	0.386
70	440/0.30	1.4	15.3	2.6	42.2	0.272
95	475/0.50	1.6	18	2.65	48.8	0.206
