-60degree ~180degree highly flexible silicone cable nautical use 0.6/1.0kV

Product Name:

-60degree ~180degree highly flexible silicone cable nautical use 0.6/1.0kV

Number :

Product Description:

-60degree ~180degree highly flexible silicone cable nautical use 0.6/1.0kV

1.Nominal Voltage: 300V / 600V

2.Nominal Temperature: -60~ +200
3.Conductor: Bare copper or tinned copper strand together with the diameter of 0.08mm
4.Insulator: Silicone Rubber
5.Colors: White-Blue-Red-Black-Brown-Yellow/Green-Transparent
6.They are the same with the inner fixed wires for airplane model, ship model, vehicle model, home appliance,
electrical machine and toys.

7.Testing Voltage: 2000V

spec of structure and technical parameters（high flexible）：
Nominal area(mm2)	Core construction	Nominal insulation thickness	Nominal OD	Maximum DC Resistance at 20℃	packing length
（mm2）	Strand/Diameter(mm)	（mm）	（mm）	（Ω/km）	（m）
0.07	19/0.07	0.5	1.3	365	500
0.1	12/0.10	0.5	1.3	188	500
0.12	32/0.07	0.5	1.4	166	500
0.15	39/0.07	0.5	1.4	136	500
0.2	53/0.07	0.5	1.4	97.8	500
0.22	45/0.08	0.5	1.6	97.8	500
0.3	59/0.08	0.5	1.6	71.2	500
0.4	105/0.07	0.5	1.8	54.8	500
0.5	100/0.08	0.6	2.16	40.1	200
0.75	384/0.05	0.6	2.4	26.7	200
1	200/0.08	0.6	2.7	20	200
1.5	304/0.08	0.7	3.3	13.7	100
2	418/0.08	0.7	3.6	10.25	100
2.5	494/0.08	0.8	4	8.21	100
4	798/0.08	0.8	4.6	5.09	100
6	1200/0.08	1	5.6	3.39	100
Noted:Other sizes and colours available on request
