Iron Cable,Electric dry iron cable

Product Features:
1, Rated voltage: 300 / 500V
2, Working temperature: -60 ~ + 500 ℃
3, Conductor: stranded pure nickel wire
4, insulation: fiberglass weave + fluorine gold mica
5, Color: Red / yellow / blue / white / black / green and yellow / brown / orange / purple / green / etc.



Applications:
Fixed laying, plus flame burning, no harmful toxic gases.
This product is a variety of electrical devices metallurgical, thermal, oil, chemicals, natural gas, kerosene and other special
circumstances, where fire performance is required.

High temperature Wire
Nominal area(mm2)	Conducotr construction	Nominal insulation thickness	Nominal OD	Maximum DC Resistance at 20℃	Packing length
（mm2）	Strand/Diameter(mm)	（mm）	（mm）	（Ω/km）	（m）
0.5	7×0.30	0.5	2.3±0.3	40.8	200
0.75	11×0.30	0.5	2.5±0.3	24.3	200
1	14×0.30	0.5	2.6±0.3	20	200
1.5	21×0.30	0.5	2.9±0.3	12.6	100
2	28×0.30	0.6	3.3±0.5	9.84	100
2.5	35×0.30	0.6	3.6±0.5	7.37	100
4	56×0.30	0.8	4.7±0.5	4.83	100
6	84×0.30	0.8	5.5±0.5	3.26	100
10	84×0.40	0.8	6.6±0.5	1.8	100
16	228×0.30	0.8	7.8±0.5	1.31	100
	126×0.40	0.8	7.8±0.5	1.31	100
25	196×0.40	0.8	9.5±0.5	0.758	100
	361×0.30	0.8	9.5±0.5	0.758	100
35	494×0.30	1	11.2±1.0	0.548	100
50	396×0.40	1.2	13.2±1.0	0.384	100
	703×0.30	1.2	13.2±1.0	0.384	100
70	551×0.40	1.2	15.4±1.0	0.289	100
	988×0.30	1.2	15.4±1.0	0.289	100
95	760×0.40	1.2	17.4±1.0	0.205	100
Noted:Other sizes and colours available on request
