Technical Parameters:

• Rated temperature: -65 ℃  -200 ℃

• Rated voltage: YGZ, YGZP: 300V / 500V

                           YGC, YGCP: 450V / 750V



Construction:

• conductor material: tinned copper wire

• shielding materials: tinned copper wire

• insulation and sheathing materials: silicone rubber

• Sheath color: red, yellow, blue, white, black, green, brown, orange, gray, etc.



Applications:

used in various mobile motor, aviation, steel, power plants, glass manufacturing, petrochemical, temperature sensors and
other high-temperature environment.

Nominal area	Conductor construction	Nominal insulation thickness	No. of cores	Nominal sheath thickness	Maximum DC Resistance at 20℃	type
(mm2)	(mm)	（mm）		（mm）	（Ω/km）
0.07	19/0.07	0.45	≤37cores	≥1.0	365	YGZ,YGZP
0.1	12/0.10	0.45			188
0.2	12/0.15	0.6			95
0.3	16/0.15	0.6			72
0.5	28/0.15	0.6			40
0.75	42/0.15	0.7		≥1.2	27
1	32/0.20	0.7			20
1.5	48/0.20	0.7		≥1.5	14
2	40/0.25	0.7			10
2.5	49/0.25	0.8			8.2
4	56/0.30	0.8	≤19cores	≥1.8	5.1	YGC,YGCP
6	84/0.30	0.8			3.4
10	84/0.40	1	≤7cores	≥2.0	1.95
16	126/0.40	1.5			1.24
25	196/0.40	1.5	≤5cores	≥2.5	0.8
35	276/0.40	1.8			0.57
50	396/0.40	1.8			0.4
70	360/0.50	2			0.28
