Product Features
Suitable for all fixed wiring switchboard/control panel applications
Significant reduction in wiring installation time due to flexibility and ease of handling
Smaller and more compact panel construction feasible due to bending radius and flexibility
Extras fine untinned copper wire ensures high flexibility
Special 105°C PVC insulation provides outstanding flexibility and mechanical strength
Self extinguishing – does not sustain combustion
All cables are metre-marked and product coded
Special cables can be supplied on request


Technical Information
Conductor:Plain annealed copper
Stranding:Class 6 to IEC 60228
Insulation:Flexible PVC
Voltage Rating:450/750V
Operating Temperature:
Minimum:0°C
Maximum:105°C
Standards:BS 6231, UL 83, CSA C22.2

spec of structure and technical parameters
Nominal area	Conductor construction	Nominal insulation thickness	Nominal braiding thickness	Nominal OD	Maximum DC Resistance at 20℃
（mm2）	Strand/Diameter(mm)	（mm）	（mm）	（mm）	（Ω/km）
0.2	12×0.15	0.5	0.15	1.8	95
0.3	16×0.15	0.5	0.15	2	71.2
0.4	23×0.15	0.5	0.15	2.2	49.6
0.5	28×0.15	0.5	0.15	2.2	40.1
0.75	42×0.15	0.5	0.15	2.5	26.7
1	32×0.20	0.5	0.15	2.7	20
1.2	40×0.20	0.5	0.15	2.8	15.9
1.5	48×0.20	0.55	0.15	3	13.7
2	40×0.25	0.6	0.15	3.4	9.9
2.5	49×0.25	0.65	0.15	3.7	8.21
4	56×0.30	0.65	0.2	4.4	5.09
6	84×0.30	0.7	0.2	5.4	3.39
10	84×0.40	0.8	0.2	6.8	1.95
16	126×0.40	1.2	0.25	8.9	1.24
25	196×0.40	1.2	0.25	10.5	0.795
35	494×0.30	1.8	0.25	13	0.565
50	396×0.40	1.8	0.3	14.8	0.393
70	551×0.40	1.8	0.3	17	0.277
Noted:Other sizes and colours available on request
