Pure nickel wire boiler application 500 degrees
 |
Product Name:
Pure nickel wire boiler application 500 degrees
Number :
 |
Product Description:
Pure nickel wire boiler application 500 degrees
Executive Standard: Q / IRMV5-2009
Product Features:
1, Rated voltage: 300 / 500V
2, Working temperature: -60 ~ + 500 ℃
3, Conductor: stranded pure nickel wire
4, insulation: fiberglass weave + fluorine gold mica
5, Color: Red / yellow / blue / white / black / green and yellow / brown / orange / purple / green / etc.
Executive Standard: Q / IRMV5-2009
Product Features:
1, Rated voltage: 300 / 500V
2, Working temperature: -60 ~ + 500 ℃
3, Conductor: stranded pure nickel wire
4, insulation: fiberglass weave + fluorine gold mica
5, Color: Red / yellow / blue / white / black / green and yellow / brown / orange / purple / green / etc.
Pure nickel wire boiler application 500 degrees
Silicone Rubber Insulated Wire
AWG
Conductor No./Dia
Overall Diameter (mm)
Insulation Thickness (mm)
Overall Diameter (mm)
Packing Length(metre)
30
7/0.103
0.31
0.76
1.83
610
28
7/0.127
0.38
0.76
1.9
610
26
7/0.160
0.49
0.76
2.01
305
24
7/0.203
0.61
0.76
2.13
305
22
7/0.254
0.76
0.76
2.28
305
20
7/0.310
0.94
0.76
2.47
305
18
7/0.39
1.17
0.76
2.71
305
16
7/0.5
1.5
0.76
3.02
305
Silicone Rubber Insulated Wire
AWG
Conductor No./Dia
Overall Diameter (mm)
Insulation Thickness (mm)
Overall Diameter (mm)
Packing Length(metre)
30
7/0.103
0.31
0.76
1.83
610
28
7/0.127
0.38
0.76
1.9
610
26
7/0.160
0.49
0.76
2.01
305
24
7/0.203
0.61
0.76
2.13
305
22
7/0.254
0.76
0.76
2.28
305
20
7/0.310
0.94
0.76
2.47
305
18
7/0.39
1.17
0.76
2.71
305
16
7/0.5
1.5
0.76
3.02
305
