Professional Supplier YH YHF Welding Cable 25mm2, 35mm2, 50mm2
 |
Product Name:
Professional Supplier YH YHF Welding Cable 25mm2, 35mm2, 50mm2
Number :
 |
Product Description:
Application
Apply to the secondary side wiring and connecting welding clamp dedicated cables, the exchange does not exceed the rated voltage 200 V DC and pulse of 400 V peak.
Single core structure, a multi-unit complex cutter made of soft wire. Conductive wire core heat-resistant polyester film used outside insulation wrap packages, with the outermost layer of insulation made of rubber sheathing as a protective layer.
Intrudction:
Welding Cables are suitable for the secondary side voltage exchange does not exceed 200 V and 400 V peak pulsating DC welding machine with secondary side wiring and connecting welding clamp purposes.
Cable allows long-term temperature: ≤ +65
Construction
Conductor : High purity electrolytic grade bright annealed flexible bunched bare copper conductor according to international standards like IS-8130, BS-6360, IEC-228 & VDE-0295
Sheath / Jacket : Oil & Water Resistant Heavy Duty Elastomer Compound of Black , Orange, Red or Yellow color ( single & double insulated )
Apply to the secondary side wiring and connecting welding clamp dedicated cables, the exchange does not exceed the rated voltage 200 V DC and pulse of 400 V peak.
Single core structure, a multi-unit complex cutter made of soft wire. Conductive wire core heat-resistant polyester film used outside insulation wrap packages, with the outermost layer of insulation made of rubber sheathing as a protective layer.
Intrudction:
Welding Cables are suitable for the secondary side voltage exchange does not exceed 200 V and 400 V peak pulsating DC welding machine with secondary side wiring and connecting welding clamp purposes.
Cable allows long-term temperature: ≤ +65
Construction
Conductor : High purity electrolytic grade bright annealed flexible bunched bare copper conductor according to international standards like IS-8130, BS-6360, IEC-228 & VDE-0295
Sheath / Jacket : Oil & Water Resistant Heavy Duty Elastomer Compound of Black , Orange, Red or Yellow color ( single & double insulated )
